28 Splines, 5-1/2" & 6-1/2" Lever Slack Adjuster
| Automann: |
135.2835, 133.2831, 135.2831 |
| Dayton: |
05-663 |
| Euclid: |
E6926, E6927B |
| Haldex: |
40010141, 40010154, 40010180, 40910408, 40910628, 40910653, 409-10814, 409-10408, 409-10650 |
| Leland: |
L3605 |
| Mack: |
25QD410P10 |
| Meritor: |
M807004, M807026, R806004, R806004A, R806026, R806026A |
| Midland: |
R806026 |
| Spline Diameter: |
1-1/2" |
| Spline Count: |
28 |
| Arm Length: |
5-1/2" & 6-1/2" |
| Body Angle: |
-34° |
| Offset: |
0 |
| Arm Hole Diameter: |
5/8" |
| Anchor Bracket Style: |
Strap |
| Grease Fitting Location: |
180° |
| Grease Fitting Type: |
Straight |
| Weight: |
7lbs |
| Longest Side | 10.63 in. |
| Median Side | 6.22 in. |
| Shortest Side | 2.56 in. |
| Weight | 7.05 lbs. |
